| Name: | Radiator thermostatic | |
| Model Number: | ||
| Warranty: | 1 year | |
| Maximum temperature: | ≤ 120°C | |
| Connection sleeve: | M30 x 1.5mm | |
| Approvals: | CE,EN215(Keymark),ISO9001,ISO14001 | |
| Adjustment scale printed on the head: | 0,*,1,2,3,4,5 | |
| Stroke: | 5.6 mm | |
| Temperature range: | 6 ~ 28 °C | |
| Housing material: | ABS injection moulding | |
| Finish: | Bright white spray paint |
The brass thermostatic radiator valve head is forged from high-quality brass and has nickel plating on the surface, which has the characteristics of corrosion resistance and oxidation resistance, effectively extending the service life. Its core adopts a thermal expansion temperature sensing element, which can accurately sense changes in room temperature (such as electrical heating, solar radiation, etc.), and automatically adjust the valve opening to ensure that the room temperature is constant within the range of 6-28°C to avoid energy waste.
Built-in stainless steel stem and spring ensure stable and reliable mechanical structure. Users can manually set the temperature through the knob, and the scale is clearly marked (such as "*" for anti-freeze mode), making it intuitive and convenient to operate.
The valve head has strong compatibility, adapts to DN15, DN20 and other pipe diameters, supports straight-through, angle, tee and other installation methods, and is widely used in residential, public buildings and industrial heating systems. Its built-in flow pre-adjustment device and water flow direction indicator facilitate maintenance and debugging, and support online cleaning or replacement of the valve spool to reduce maintenance costs.
In addition, brass valve heads can reduce energy waste through precise temperature control, and experiments have shown that they can save 10%-20% of energy, which is both economical and environmentally friendly, and is an ideal choice for efficient regulation of heating systems.
