| Name: | Radiator thermostatic | |
| Model Number: | ||
| Warranty: | 1 year | |
| Maximum temperature: | ≤ 120°C | |
| Connection sleeve: | M30 x 1.5mm | |
| Approvals: | CE,EN215(Keymark),ISO9001,ISO14001 | |
| Adjustment scale printed on the head: | 0,*,1,2,3,4,5 | |
| Stroke: | 5.6 mm | |
| Temperature range: | 6 ~ 28 °C | |
| Housing material: | ABS injection moulding | |
| Finish: | Injection molded white |
Standardised interface design
adopts universal M30×1.5mm threaded interface, perfectly adapted to mainstream floor heating manifolds, no need to transfer fittings during installation, greatly reducing construction complexity, suitable for engineering bulk purchase and installation.
Intelligent temperature control
Built-in high-precision NTC temperature sensor, real-time monitoring of the ambient temperature and automatically adjust the water flow, temperature control accuracy of ± 0.5 ℃, to avoid local overheating or low temperature, to enhance the comfort of the floor heating system.
Engineering grade durable structure
The valve body is made of forged brass, no leakage in long-term use, especially suitable for commercial/residential underfloor heating with high usage frequency.
Energy-saving optimised design
supports 5-60°C wide range temperature regulation, with time programming function (optional), it can set up time-sharing temperature strategy, which saves more than 25% energy compared with traditional valves, and reduces the operating cost of central heating system.
Batch stable quality
Fully automated production line ensures product consistency, and each batch of thermostat head passes 72 hours aging test (including -15℃ freezing/85℃ high temperature cycle), which guarantees the reliability when purchasing in large quantities.
Maintenance Convenience
The top knob can be quickly disassembled for easy cleaning of the filter; the valve body is reserved with a manual override notch, which can be adjusted with a tool in case of sudden power failure in an emergency to ensure uninterrupted operation of the system.
